This official Caterpillar Electrical and Hydraulic Schematic Manual is for the 336D2 L XE Excavator with Serial Number prefix MEH. It provides complete factory-verified diagrams and schematics covering all electrical and hydraulic systems, ensuring precise troubleshooting, repair, and servicing. The electrical section includes wiring diagrams, harness layouts, relays, fuses, switches, sensors, and control modules. The hydraulic schematics detail pumps, valves, motors, cylinders, hose routing, and fluid flow paths, supporting effective maintenance and minimizing downtime. With accurate Caterpillar engineering, clear illustrations, and easy-to-follow layouts, this manual is an indispensable tool for technicians, engineers, and owners maintaining the 336D2 L XE Excavator.

Includes ALL DIAGRAMS & PICTURES for 336D2 L XE EXCAVATOR MEH
Format: PDF
Language: English
Download Instructions: PDF will be delivered to your email after purchase
